2026 QuadSport Z90

2026 QuadSport Z90 Overview

The 2026 Suzuki QuadSport Z90 is the ideal ATV for adult-supervised riders ages twelve and older to develop their off-road riding skills. Convenient features like an automatic transmission and electric starter help make this ATV easy to operate. To help young beginners grow into accomplished ATV riders, the Z90 includes a keyed ignition switch and throttle limiter to adjust engine performance to the operator’s skill level.

Get young riders started on the QuadSport Z90, so the whole family can experience the fun of the outdoors and the joy of riding a Suzuki!


Find a Dealer

Gallery

Champion Yellow No. 2

Key Features

View Product Brochure

Compact and durable, 90cc, single cylinder, air-cooled engine has an easy electric starting system plus a standard backup recoil starter. The QuadSport Z90’s four-stroke engine complies with Environmental Protection Agency (EPA) emissions regulations.

Smooth-running CVT automatic transmission provides effortless operation and allows the rider to focus on riding instead of shifting. Speed-limiter collar in the automatic clutch limits top speed to 15 mph and can be removed to increase top speed as the rider gains ability.

Single A-arm front suspension with twin, independent shock absorbers and single-shock rear suspension provides long wheel travel for the one-piece, eight-inch wheels with tubeless tires that provide a smooth, comfortable ride.

A keyed ignition switch lets supervising adults decide when the action begins and ends. A simple, screw-type throttle limiter allows adult supervisors to limit the maximum power delivery to suit the rider's ability.

Compact, 90cc, four-stroke, single-cylinder, air-cooled engine is designed for durability and minimal maintenance.

Large 1.6-gallon (6.0-liter) fuel tank provides long riding time. A vacuum-operated fuel petcock automatically stops fuel flow when the engine’s not running.

A keyed ignition switch lets supervising adults decide when the action begins and ends.

Speed-limiter collar in the automatic clutch limits top speed to 15 mph. The collar can be removed to increase top speed as the rider gains ability.

Smooth-running CVT automatic transmission provides effortless operation and allows the rider to focus on riding instead of shifting.

Single A-arm front suspension with twin, independent shock absorbers and single-shock rear suspension provides long wheel travel for a smooth, comfortable ride.

Rear axle shaft has double oil seals for performance and reliability.

Large-diameter, semi-sealed front drum brakes, and single fully sealed rear drum brake help provide strong braking performance.

Strong, high-rigidity steel frame is sturdy and compact.

Modern styling with full floorboards blends to create a big Quad look that youth riders will admire.

Competition-inspired Champion Yellow No, 2 body and fenders with blue, black, and red graphics.

Suzuki 12-month limited warranty is double the length of most other youth ATV warranties. Longer coverage and other benefits are available through Suzuki Extended Protection (SEP).

A variety of Genuine Suzuki Accessories for QuadSport owners are available, including a wide selection of Suzuki logo apparel.

Specifications

  • Engine90cc, 4-stroke, air-cooled, single cylinder, OHC
  • Bore x Stroke45.5 mm x 55.2 mm (1.791 in. x 2.173 in.)
  • Compression Ratio9.5:1
  • Fuel SystemMikuni VM16, single carburetor
  • StarterElectric and back-up recoil
  • LubricationWet sump
  • TransmissionCVT automatic
  • ClutchDry shoe, automatic, centrifugal type
  • Driven Wheels2WD
  • Final DriveChain, RK530, 60 links
  • Suspension FrontIndependent, swing axle, coil spring, oil damped
  • Suspension RearSwingarm type, coil spring, oil damped
  • Brakes FrontTwin drum brakes
  • Brakes RearSingle drum brake
  • Tires FrontAT19 × 7-8, tubeless type x 2
  • Tires RearAT19 × 7-8, tubeless type x 2
  • Fuel Tank Capacity1.6 US gal. (6.0 L)
  • ColorChampion Yellow No. 2
  • IgnitionElectronic ignition (CDI)
  • HeadlightN/A
  • Tail LightN/A
  • Overall Length1505 mm (59.3 in.)
  • Overall Width875 mm (34.4 in.)
  • Overall Height915 mm (36.0 in.)
  • Wheelbase1005 mm (39.6 in.)
  • Ground Clearance150 mm (5.9 in.)
  • Seat Height650 mm (25.6 in.)
  • Curb Weight127 kg (280 lb.)
  • Warranty12-month limited warranty
  • ExtensionLonger coverage periods with other benefits are available through Suzuki Extended Protection (SEP)
